腾讯实时音视频(Tencent Real-Time Communication,TRTC)是腾讯云提供的一套低延时、高质量的音视频通信服务。本文将详细介绍如何在 uni-app 和 Web 端接入 TRTC,并提供完整的示例代码,包括多人视频通话的实现。

· 5 min read
LIU

技术方案

1. IndexedDB

IndexedDB 是一个强大的浏览器内置数据库,具有以下优势:

  • 支持存储大量结构化数据
  • 支持索引,便于快速检索
  • 支持事务,保证数据一致性
  • 异步 API,不会阻塞主线程

2. 数据加密:jsencrypt

使用 jsencrypt 进行数据加密,确保离线数据的安全性:

  • 使用 RSA 非对称加密
  • 公钥加密,私钥解密
  • 保证数据在本地存储的安全性

核心实现

1. IndexedDB 数据库设计

// db.js
const DB_NAME = "medical_reports";
const DB_VERSION = 1;

const initDB = () => {
return new Promise((resolve, reject) => {
const request = indexedDB.open(DB_NAME, DB_VERSION);

request.onerror = () => reject(request.error);
request.onsuccess = () => resolve(request.result);

request.onupgradeneeded = (event) => {
const db = event.target.result;

// 报告基本信息表
if (!db.objectStoreNames.contains("reports")) {
const reportStore = db.createObjectStore("reports", { keyPath: "id" });
reportStore.createIndex("patientId", "patientId", { unique: false });
reportStore.createIndex("timestamp", "timestamp", { unique: false });
}

// 波形数据表
if (!db.objectStoreNames.contains("waveforms")) {
const waveformStore = db.createObjectStore("waveforms", {
keyPath: "id",
});
waveformStore.createIndex("reportId", "reportId", { unique: false });
}
};
});
};

2. 数据加密存储

// encryption.js
import JSEncrypt from "jsencrypt";

const encrypt = new JSEncrypt();
encrypt.setPublicKey(process.env.VUE_APP_PUBLIC_KEY);

export const encryptData = (data) => {
return encrypt.encrypt(JSON.stringify(data));
};

export const decryptData = (encryptedData) => {
const decrypt = new JSEncrypt();
decrypt.setPrivateKey(process.env.VUE_APP_PRIVATE_KEY);
return JSON.parse(decrypt.decrypt(encryptedData));
};

3. Vue 组件实现

<!-- ReportViewer.vue -->
<template>
<div class="report-viewer">
<div v-if="loading" class="loading">
<loading-spinner />
</div>
<template v-else>
<div class="report-header">
<h1>{{ report.title }}</h1>
<div class="meta-info">
<span>患者:{{ report.patientName }}</span>
<span>时间:{{ formatDate(report.timestamp) }}</span>
</div>
</div>

<div class="report-content">
<div class="waveform-container">
<waveform-chart :data="waveformData" />
</div>
<div class="report-text">{{ report.content }}</div>
</div>
</template>
</div>
</template>

<script>
import { initDB } from "@/utils/db";
import { decryptData } from "@/utils/encryption";
import WaveformChart from "./WaveformChart.vue";
import LoadingSpinner from "./LoadingSpinner.vue";

export default {
name: "ReportViewer",
components: {
WaveformChart,
LoadingSpinner,
},
data() {
return {
loading: true,
report: null,
waveformData: null,
db: null,
};
},
async created() {
try {
this.db = await initDB();
await this.loadReport();
} catch (error) {
console.error("Failed to load report:", error);
} finally {
this.loading = false;
}
},
methods: {
async loadReport() {
const reportId = this.$route.params.id;

// 从 IndexedDB 加载报告数据
const report = await this.getReportFromDB(reportId);
const waveform = await this.getWaveformFromDB(reportId);

// 解密数据
this.report = decryptData(report.encryptedData);
this.waveformData = decryptData(waveform.encryptedData);
},
async getReportFromDB(id) {
return new Promise((resolve, reject) => {
const transaction = this.db.transaction(["reports"], "readonly");
const store = transaction.objectStore("reports");
const request = store.get(id);

request.onsuccess = () => resolve(request.result);
request.onerror = () => reject(request.error);
});
},
async getWaveformFromDB(reportId) {
return new Promise((resolve, reject) => {
const transaction = this.db.transaction(["waveforms"], "readonly");
const store = transaction.objectStore("waveforms");
const index = store.index("reportId");
const request = index.get(reportId);

request.onsuccess = () => resolve(request.result);
request.onerror = () => reject(request.error);
});
},
formatDate(timestamp) {
return new Date(timestamp).toLocaleString();
},
},
};
</script>

<style scoped>
.report-viewer {
padding: 20px;
}

.loading {
display: flex;
justify-content: center;
align-items: center;
min-height: 400px;
}

.report-header {
margin-bottom: 20px;
}

.meta-info {
color: #666;
font-size: 14px;
}

.meta-info span {
margin-right: 20px;
}

.waveform-container {
margin: 20px 0;
border: 1px solid #eee;
border-radius: 4px;
padding: 10px;
}

.report-text {
line-height: 1.6;
}
</style>

性能优化

1. 数据预加载

// preload.js
export const preloadReports = async (db, reportIds) => {
const transaction = db.transaction(["reports", "waveforms"], "readonly");
const reportStore = transaction.objectStore("reports");
const waveformStore = transaction.objectStore("waveforms");

const reports = await Promise.all(reportIds.map((id) => reportStore.get(id)));

const waveforms = await Promise.all(
reportIds.map((id) => {
const index = waveformStore.index("reportId");
return index.get(id);
})
);

return { reports, waveforms };
};

2. 数据分片存储

对于大型波形数据,采用分片存储策略:

// waveformStorage.js
const CHUNK_SIZE = 1024 * 1024; // 1MB per chunk

export const storeWaveform = async (db, reportId, waveformData) => {
const chunks = splitIntoChunks(waveformData, CHUNK_SIZE);

const transaction = db.transaction(["waveforms"], "readwrite");
const store = transaction.objectStore("waveforms");

for (let i = 0; i < chunks.length; i++) {
await store.put({
id: `${reportId}_${i}`,
reportId,
chunkIndex: i,
data: chunks[i],
});
}
};

const splitIntoChunks = (data, size) => {
const chunks = [];
for (let i = 0; i < data.length; i += size) {
chunks.push(data.slice(i, i + size));
}
return chunks;
};

使用效果

通过以上实现,我们达到了以下目标:

  1. 首屏加载时间 < 1s

    • 使用 IndexedDB 的索引功能实现快速检索
    • 数据预加载策略
    • 分片存储大型波形数据
  2. 完整的离线功能

    • 支持查看完整的报告内容
    • 包含波形图等复杂数据
    • 数据加密存储保证安全性
  3. 良好的用户体验

    • 流畅的加载过程
    • 响应式界面设计
    • 错误处理和加载状态提示

注意事项

  1. 定期清理过期数据,避免存储空间占用过大
  2. 实现数据同步机制,确保离线数据与服务器数据的一致性
  3. 考虑添加数据压缩功能,进一步优化存储空间
  4. 实现错误重试机制,提高系统稳定性

· 7 min read
LIU

Vue2 与 Vue3 的 Diff 算法对比

Vue 的虚拟 DOM 和 Diff 算法是其高效渲染的核心。Vue3 在 Vue2 的基础上对 Diff 算法进行了重大优化,本文将深入对比两者的差异,并分析这些优化带来的性能提升。

1. 虚拟 DOM 基础

虚拟 DOM 结构

Vue2 和 Vue3 的虚拟 DOM 结构有所不同:

// Vue2 的虚拟 DOM 结构
{
tag: 'div',
data: {
attrs: { id: 'app' },
on: { click: handler }
},
children: [
{
tag: 'span',
data: { attrs: { class: 'text' } },
children: ['Hello']
}
]
}

// Vue3 的虚拟 DOM 结构
{
type: 'div',
props: {
id: 'app',
onClick: handler
},
children: [
{
type: 'span',
props: { class: 'text' },
children: ['Hello']
}
]
}

主要区别

  1. Vue3 使用 type 替代 tag 表示节点类型
  2. Vue3 扁平化处理 props,不再区分 attrs 和 on
  3. Vue3 的虚拟 DOM 结构更加简洁,减少了内存占用

2. Diff 算法核心流程

Vue2 的 Diff 算法

Vue2 的 Diff 算法采用双端比较的方式:

function updateChildren(parentElm, oldCh, newCh) {
let oldStartIdx = 0
let oldEndIdx = oldCh.length - 1
let newStartIdx = 0
let newEndIdx = newCh.length - 1

while (oldStartIdx <= oldEndIdx && newStartIdx <= newEndIdx) {
if (sameVnode(oldCh[oldStartIdx], newCh[newStartIdx])) {
patchVnode(oldCh[oldStartIdx], newCh[newStartIdx])
oldStartIdx++
newStartIdx++
} else if (sameVnode(oldCh[oldEndIdx], newCh[newEndIdx])) {
patchVnode(oldCh[oldEndIdx], newCh[newEndIdx])
oldEndIdx--
newEndIdx--
} else if (sameVnode(oldCh[oldStartIdx], newCh[newEndIdx])) {
patchVnode(oldCh[oldStartIdx], newCh[newEndIdx])
parentElm.insertBefore(oldCh[oldStartIdx].elm, oldCh[oldEndIdx].elm.nextSibling)
oldStartIdx++
newEndIdx--
} else if (sameVnode(oldCh[oldEndIdx], newCh[newStartIdx])) {
patchVnode(oldCh[oldEndIdx], newCh[newStartIdx])
parentElm.insertBefore(oldCh[oldEndIdx].elm, oldCh[oldStartIdx].elm)
oldEndIdx--
newStartIdx++
} else {
// 创建 key 到 index 的映射
const idxInOld = createKeyToOldIdx(oldCh, oldStartIdx, oldEndIdx)
const idxInNew = newCh[newStartIdx].key

if (idxInOld[idxInNew]) {
// 移动节点
const vnodeToMove = oldCh[idxInOld[idxInNew]]
patchVnode(vnodeToMove, newCh[newStartIdx])
oldCh[idxInOld[idxInNew]] = undefined
parentElm.insertBefore(vnodeToMove.elm, oldCh[oldStartIdx].elm)
} else {
// 创建新节点
createElm(newCh[newStartIdx], parentElm, oldCh[oldStartIdx].elm)
}
newStartIdx++
}
}
}

Vue3 的 Diff 算法

Vue3 采用快速 Diff 算法,主要优化点:

function patchKeyedChildren(c1, c2, container) {
let i = 0
let e1 = c1.length - 1
let e2 = c2.length - 1

// 1. 从头部开始比较
while (i <= e1 && i <= e2 && c1[i].key === c2[i].key) {
patch(c1[i], c2[i], container)
i++
}

// 2. 从尾部开始比较
while (i <= e1 && i <= e2 && c1[e1].key === c2[e2].key) {
patch(c1[e1], c2[e2], container)
e1--
e2--
}

// 3. 处理新增和删除的节点
if (i > e1) {
// 新增节点
const nextPos = e2 + 1
const anchor = nextPos < c2.length ? c2[nextPos].el : null
while (i <= e2) {
patch(null, c2[i], container, anchor)
i++
}
} else if (i > e2) {
// 删除节点
while (i <= e1) {
unmount(c1[i])
i++
}
} else {
// 4. 处理未知序列
const s1 = i
const s2 = i
const keyToNewIndexMap = new Map()

// 建立新子节点的 key 到 index 的映射
for (let i = s2; i <= e2; i++) {
keyToNewIndexMap.set(c2[i].key, i)
}

// 更新和移动节点
let moved = false
let maxNewIndexSoFar = 0
const toBePatched = e2 - s2 + 1
const newIndexToOldIndexMap = new Array(toBePatched).fill(0)

for (let i = s1; i <= e1; i++) {
const oldVNode = c1[i]
const newIndex = keyToNewIndexMap.get(oldVNode.key)

if (newIndex === undefined) {
unmount(oldVNode)
} else {
newIndexToOldIndexMap[newIndex - s2] = i + 1
if (newIndex >= maxNewIndexSoFar) {
maxNewIndexSoFar = newIndex
} else {
moved = true
}
patch(oldVNode, c2[newIndex], container)
}
}

// 移动节点
if (moved) {
const seq = getSequence(newIndexToOldIndexMap)
let j = seq.length - 1
for (let i = toBePatched - 1; i >= 0; i--) {
const nextIndex = s2 + i
const nextChild = c2[nextIndex]
const anchor = nextIndex + 1 < c2.length ? c2[nextIndex + 1].el : null

if (newIndexToOldIndexMap[i] === 0) {
patch(null, nextChild, container, anchor)
} else if (moved) {
if (j < 0 || i !== seq[j]) {
move(nextChild, container, anchor)
} else {
j--
}
}
}
}
}
}

3. 主要优化点

静态标记

Vue3 引入了静态标记(PatchFlag),用于标记动态内容:

// Vue3 的静态标记示例
const vnode = {
type: 'div',
props: {
id: 'app',
class: 'container'
},
children: [
{
type: 'span',
props: { class: 'text' },
children: ['Hello'],
patchFlag: 1 // 表示文本内容可能变化
}
]
}

静态提升

Vue3 将静态节点提升到渲染函数之外:

// Vue3 的静态提升
const hoisted = createVNode('div', null, '静态内容')

function render() {
return createVNode('div', null, [
hoisted,
createVNode('span', null, state.message)
])
}

事件监听器缓存

Vue3 缓存事件监听器,避免重复创建:

// Vue3 的事件监听器缓存
const render = (ctx) => {
return createVNode('button', {
onClick: ctx.onClick // 事件监听器被缓存
}, '点击')
}

4. 性能对比

时间复杂度

  • Vue2: O(n²)
  • Vue3: O(n)

内存占用

  • Vue2: 较大的内存占用
  • Vue3: 显著减少的内存占用

实际性能提升

  1. 首次渲染性能提升约 50%
  2. 更新性能提升约 100%
  3. 内存占用减少约 50%

5. 最佳实践

合理使用 key

<!-- 推荐:使用唯一且稳定的 key -->
<template v-for="item in items" :key="item.id">
<div>{{ item.name }}</div>
</template>

<!-- 不推荐:使用索引作为 key -->
<template v-for="(item, index) in items" :key="index">
<div>{{ item.name }}</div>
</template>

避免不必要的更新

// 使用 shallowRef 减少响应式开销
const state = shallowRef({
count: 0,
user: {
name: 'John'
}
})

// 使用 markRaw 标记不需要响应式的对象
const staticData = markRaw({
config: {
theme: 'dark'
}
})

合理使用组件

<!-- 使用异步组件减少初始加载时间 -->
const AsyncComponent = defineAsyncComponent(() =>
import('./HeavyComponent.vue')
)

<!-- 使用 keep-alive 缓存组件状态 -->
<keep-alive>
<component :is="currentComponent" />
</keep-alive>

6. 总结

Vue3 的 Diff 算法相比 Vue2 有了显著的改进:

  1. 采用快速 Diff 算法,时间复杂度从 O(n²) 降低到 O(n)
  2. 引入静态标记和静态提升,减少不必要的更新
  3. 优化事件监听器,减少内存占用
  4. 提供更多性能优化 API,如 shallowRef、markRaw 等

这些优化使得 Vue3 在性能上有了质的飞跃,特别是在大型应用中,性能提升更为明显。开发者应该充分了解这些优化,并在实际开发中合理运用,以充分发挥 Vue3 的性能优势。

· 5 min read
LIU

Vue.js 是一个渐进式JavaScript框架,其源码设计精巧,包含了响应式系统、虚拟DOM、模板编译等核心功能。本文将从源码角度深入分析Vue2的核心实现原理。

· 9 min read
LIU

1.元素挂载顺序

vue元素挂载的顺序之分

  1. 如果存在render函数,就用render函数渲染组件;
  2. 如果没有render函数,但是存在template,就将template中的内容编译成render函数,最后做渲染;
  3. 如果既没有render函数也没有template函数,就获取el里的内容作为template,同样编译成render函数。
  Vue.prototype.$mount = function (el) {
// 挂载
const vm = this;
const options = vm.$options;
el = document.querySelector(el);
vm.$el = el;
if(!options.render) { // 没有render方法
let template = options.template;
if(!template && el){ // 没有template 但是有el 获取el中的内容
template = el.outerHTML
}
// 将模板编译成render函数
const render = compileToFunctions(template)
options.render = render;
}
// 渲染时用的都是render函数
// 挂载组件
mountComponent(vm,el);
}

· 6 min read
LIU

错误的分类

  • 代码运行错误:也称为代码错误。这个错误一般在代码书写时造成的,比如语法错误、逻辑错误,这样的错误通常在开发或测试阶段就会被发现
  • 资源加载错误:这个错误通常是找不到文件(404)或者是文件加载超时出现的

代码运行错误

SyntaxError 解析时发生语法错误

const abc

window.onerror捕获不到SyntxError,一般SyntaxError在构建阶段,或是本地开发阶段就会被抛出

TypeError 值不是所期待的类型

· 5 min read
LIU

业务模块

...

项目依赖

注:node > v12.0.0

{
"axios": "^0.24.0",
"vant": "^3.2.8",
"vue": "^3.2.16",
"vue-router": "^4.0.12",
"vuex": "^4.0.2",
"sass": "^1.43.4",
"typescript": "^4.4.3",
"vite": "^2.6.4",
}

· 12 min read
LIU

1.开始

Node.js 是一个开源和跨平台的 JavaScript 运行时环境。它几乎是任何类型项目的流行工具

Node.js 应用程序在单个进程中运行,无需为每个请求创建新的线程。Node.js 在其标准库中提供了一组异步的I/O原语,以防止 JavaScript 代码阻塞,通常,Node.js 中的库是使用非阻塞范式编写的

2.非阻塞

node 核心运行机制,node应用运行在单个进程中,node是单线程的(意思是node中只有一个线程用于处理 javascript),一个进程包含多个线程

image-20220613120754407

· 11 min read
LIU

时间复杂度

一般看的都是 O(1) ~ O(n^2) 范围,其它都是需要优化的

  • O(1)

    • if(i==1)
    • res = 100 1000、res = n 200
    • push(2)、pop()
    • map.set(1,1)、map.get(1)
    • 计算复杂度时,O(1)一般会被忽略
  • O(n)

    • for循环,while循环(不使用二分搜索)
  • O(log n)

    • 二分搜索
